Transport data logger ASPION G-Log 2:
Transparency for your supply chain!
ASPION G-Log 2 records shock and climatic conditions
The new transport data logger ASPION G-Log 2 measures and records shock events - traceable in all three axes and for the highest shocks up to millisecond level. At the same time, it records climate data such as temperature and relative humidity based on intervals or events. This makes the transport loads and environmental conditions for your goods transparent, traceable and assignable at all times - especially in the event of damage. Reduce costs for transport damage and increase your process quality!
ASPION G-Log 2 Waterproof
The waterproof version of the G-Log 2 is suitable for outdoor applications with protection class IP65/67.
First data logger for monitoring shock/vibration according to transport standard
The shock/vibration test according to the transport standard IEC 60721-3-2 is unique: The data logger compares shocks and vibrations against the selected standard and class. For the first time, this makes testing transport conditions as easy in practice as, for example, proving compliance with a cold chain!
This results in real added value for companies: for the first time, transport damage can be detected cost-effectively even without specialist expertise. For its innovative implementation, the ASPION G-Log 2 was awarded the Best of Industry Award 2022 as the winner in the sensor technology category.
The advantages at a glance
Reliable
Records vibrations of up to ± 24 g on 3 axes and climate data - event and interval based.
Compact
Small, compact, lightweight and robust in ABS housing with IP 50.
Durable
Multi-purpose, durable and with replaceable battery for resource-saving use.
Inexpensive
The best price/performance ratio with unique detail accuracy for fast damage clarification.
Simple
Extremely simple operation with indication of threshold values and optional precise time-controlled recording.
Ergonomic
An ergonomically operable PC software, easy-to-create reports and clear evaluations - for enthusiastic users.
Flexible
The recorded data can be read out and transmitted via smartphone app at any time and from any location.
Air Freight & Industries
The G-Log shock sensor is suitable for air freight and can be used universally in all industries.
Made in Germany
Completely developed and manufactured in Germany.
The shock and climate data recording of the transport data logger
ASPION G-Log 2 provides meaningful details: Serious damage can be detected directly! The short video explains the details.
Fields of application
The new ASPION G-Log 2 - just like its little brother ASPION G-Log - has been specially developed for the transport monitoring of sensitive goods and products. The transport data loggers collect valuable information especially for manufacturers in the machine and plant construction, automotive and electronics industries, energy sector as well as logistics and packaging industry. In addition, the data loggers are successfully used by companies in a wide range of industries for testing packaging, shocks during loading, vibration tests and much more.
With the option to switch off shock recording and the intelligent recording of climate data such as temperature and relative humidity - interval and event-triggered - the data logger is suitable for checking temperature and humidity-sensitive products during transport and in the warehouse.
How it works
The ASPION G-Log 2 data logger is attached directly to the transported goods, initialized with threshold values and activated immediately or time-controlled. During the entire transport route, it stores events that occur: Shocks, temperature and humidity fluctuations that lie outside the preset tolerance limits - or permanently within the set interval. Equipped with NFC and BLE for wireless communication, the data can be read, evaluated and transmitted at any time using the smartphone app. The analysis of the data is carried out conveniently with the free PC software.
(Video in German language)
Meaningful details at millisecond level
The data of a shock event in detail are essential for evaluations and interpretation in the event of damage. The sensor records the temporal course of a shock on all three axes on the millisecond level. This section of a total of 19 values is used for the exact analysis of the course, allows conclusions to be drawn about the effects and can make a significant contribution to the assessment in the event of damage and to packaging optimization. All in all, a sensor permanently stores the very first shock event as well as the other eight highest shock events in this granularity. Thus the ASPION shock sensors deliver a unique depth of detail in contrast to all other data loggers in the same price range.
How to evaluate your data: All details on the analysis of impact / shock
New: Activation now also possible via app
ASPION G-Log 2 shock and climate loggers can be activated flexibly, quickly and easily directly via smartphone app for the first time with the new version 6. The activation takes place in interaction with the cloud service ASPION G-Log Premium. This means that you receive each new activation automatically in your PC software. You thus retain full control and transparency over all data loggers used at all times and from any location.
Order now
The ASPION G-Log 2 starter package contains:
- 2 data loggers for shock and climate
- 1 USB card reader
- 2 sticker "data logger inside"
- Software and App
Price: 289 Euro *
Order your starter package now and protect your goods.
Currently all data loggers are available from stock.
Sets with bulk discounts are available for further expansion.
* Please note that all prices are exclusive of taxes, customs duties and shipping costs. Actual prices and delivery times may vary depending on region, country and currency. For details, please contact our respective distribution partners directly or send us an inquiry to info@aspion.de.
